Description
FAAC E024U Metal Enclosure Solar Kit for Electromechanical Operator (without Solar Panel) | FAA-5554.1
Includes
- 18” x 16” metal enclosure
- Backplate with solar charger and switch
- E024U control board
- Batteries not included
Features
- UL325 and UL991 safety standard compliant
- Powerful and efficient switching Power Supply
- Easy Programming with trimmers and dip switches
- One pushbutton automatic time learning
- Self-resetting fuses
- Built-in battery backup
- Low current idle mode to preserve battery
- Opening and closing delays selectable for overlapping gates
- Speed and force adjustable with trimmers
- Control Board firmware upgradable via USB
- Solar Powered option
- Battery switch/over-current protection
- Enclosure:
- Aluminum construction
- Powder-coated
- Post-mount options built-in
- Pre-punched holes for conduit
Technical Specifications
- Input Voltage: 115 VAC (+10% -6%)
- Input power: 400 W max – 4W stand by
- Motor output current max: 7 A
- Accessory Power: 24 Vdc – 500 mA
- Operating Temperature: -4°F – 131°F (-20°C – +55°C)
- Dimensions: 16.375 x 6.25 x 17.875 in
- Weight (with batteries): 26 lb
- Protection class: IP54
- Semiautomatic (E)
- Automatic (A)
- Security (S)
- Semiautomatic step by step (EP)
- Automatic step by step (AP)
- Security step by step (SP)
- Manned pulsed (B)
- Manned constant
