FAAC J275 HA 2K20 Retractable Security Bollard | FAA-116401

Description

FAAC J275 HA 2K20 Retractable Security Bollard | FAA-116401

J275 HA 2K20 Retractable Security Bollard

The J275 HA 2K20 comes with:

• Steel cylinder with cataphoresis treatment and metalized dark grey powder-coated paint
• Flashing LED lights ring
• Audible buzzer (active during movement)
• Anti-tampering head with encrypted manual release key
• Hydraulic lock in raised position (in case of a power failure)

Please Note

This product is a special order and is not eligible for returns or refunds.
The standard lead time is 8 weeks.

Features

• Performance certified according to PAS 68 and IWA 14-1 standards. Able to withstand impact with a 16,500 lb truck driven at 28 mph in a dual-unit configuration
• Guaranteed for high-frequency use
• Simple maintenance (just one person needed)
• Hydraulic control unit integrated into the bollard
• Built-in hydraulic slow down for softer landing in the opening
• Anti-tamper head protected by a security lock with an encrypted key to prevent unauthorized opening

Manufacturer’s Warranty Period

• 2 years

Technical Specifications

• Drive: Hydraulic Unit
• Cylinder stroke: 31.5 in (800 mm)
• Cylinder diameter: 10.8 in (275 mm)
• Cylinder treatment: Cataphoresis and polyester painting
• Reflective strip height: 2.16 in (55 mm)
• Standard reflecting strip color: White
• Rising time: Approx. 8 s
• Descent time: Approx. 4.5 s
• Emergency descent device: YES (with optional solenoid valve unit)
• Emergency descent time: Approx. 2 s
• Rising obstacle detection device: YES (with optional pressure switch)
• Release device: yes
• Slow lowering: yes
• Power supply voltage: 220-240V – 50/60Hz
• Max. power: 575 W
• Hydraulic pump unit protection class: IP67
• Type of use: Perimeter protection
• Break in resistance: 673,000 J dual unit
• Pit weight: 220 lb. (100 kg)
• Traffic bollard weight: 375 lb. (170 kg)
• Operating ambient temperature: 5°F – 131°F (-15 °C / +55 °C)
• Operating ambient temperature with heater: -13°F – 131°F (-25 °C / +55 °C)
• Load class: (EN 124) C250 (25 metric ton)
